PERFINO VERTICAL

Colour. Amplified.
Magnetising displays to ignite your sales

The iconic Perfino range from Nualight. The industry’s leading LED lighting solution for colour rich and vibrant displays. Perfino casts a rich and uniform light, providing a highly enticing and comfortable ambience and one void of dark spots and hot dots. Perfino’s precisely engineered optics puts the light where it is needed most. Centre and end variants ensure there is no wasted light as Perfino illuminates into the depth of the case rather than the surrounding mullions. Perfino is the premium solution to application specific colours as seen in older installations. A a true-white LED solution with market-leading colour vibrancy all the way through the spectrum. Perfino can be installed in all areas of the store from bakery and grocery to fresh meat and fish counters. The robust IP67 Perfino family contains horizontal and vertical solutions which can be used in a variety of remote display chiller and freezer case models from open multideck and islands to closed door verticals. Perfino is available in a range of lengths, powers and colour temperatures. Installation accessories including mullion clips, various brackets and cables are available separately to order.

Request a call back

Movie

open all | close all

Overview

Key Benefits

Colour-rich, smooth and uniform lighting
One solution for the complete store
True-white LED solution with high CRI (Vivace) from R1-R17
Reds appear richer, blues and greens reflect freshness

Applications

Refrigeration
Bakery
Dairy
Drinks
Fresh Fish
Fresh Meat
Frozen
Grocery

Availability

Call +353 21 486 7636 for more information

Specification

Performance

Colour rendering (CRI):

Electrical class:

Class III

IK rating:

IK02

IP rating:

IP67

LED quality (SDCM):

Operating temperature (C):

-30 to +35

Operating voltage:

24VDC

Power factor:

0.95

Rated lifetime:

50,000 Hours

Installation / Mounting

Cables and brackets are not included as standard

Materials / Finish

Range contains white RAL9016 polycarbonate extrusion

Standards

EN60598-1,EN60598-2-1,EN60335-2-24,EN60335-2-89,EN62031,EN62471,EN61547,EN62493,EN55015,EN61000-3-2,EN61000-3-3,EN61000-4-2,EN61000-4-3,EN61000-4-4,EN61000-4-5,EN61000-4-6,EN61000-4-8

Patents

All patents granted US7,513,637; US7,976,181; US 7,871,176; EP1,828,678

Learning Zone

Downloads

All LDT files as Zip

All Datasheets as Zip

Family Datasheet EN

Family Datasheet DE

Declaration of Conformity

Installation Sheet

Ordering Guide

Description	Power (W)	Lumens (lm)	Efficacy (lm/w)	SKU		Datasheet
PERFINO V CHILLER 1176 3000K CENTRE	23	2150	95	N17289-6X	LDT	EN - DE
PERFINO V CHILLER 1176 3500K CENTRE	23	2150	95	N17290-6X	LDT	EN - DE
PERFINO V CHILLER 1176 4000K CENTRE	23	2150	95	N17291-6X	LDT	EN - DE
PERFINO V CHILLER 1476 3000K CENTRE	29	2750	95	N17294-6X	LDT	EN - DE
PERFINO V CHILLER 1476 3500K CENTRE	29	2750	95	N17295-6X	LDT	EN - DE
PERFINO V CHILLER 1476 4000K CENTRE	29	2750	95	N17296-6X	LDT	EN - DE
PERFINO V CHILLER 1676 3000K CENTRE	33	3100	95	N17299-6X	LDT	EN - DE
PERFINO V CHILLER 1676 4000K CENTRE	33	3100	95	N17301-6X	LDT	EN - DE
PERFINO V CHILLER 1176 3000K END	14.5	1300	90	N17309-6X	LDT	EN - DE
PERFINO V CHILLER 1176 3500K END	14.5	1300	90	N17310-6X	LDT	EN - DE
PERFINO V CHILLER 1176 4000K END	14.5	1300	90	N17311-6X	LDT	EN - DE
PERFINO V CHILLER 1476 3000K END	18.5	1650	90	N17314-6X	LDT	EN - DE
PERFINO V CHILLER 1476 3500K END	18.5	1650	90	N17315-6X	LDT	EN - DE
PERFINO V CHILLER 1476 4000K END	18.5	1650	90	N17316-6X	LDT	EN - DE
PERFINO V CHILLER 1676 3000K END	21	1875	90	N17319-6X	LDT	EN - DE
PERFINO V CHILLER 1676 4000K END	21	1875	90	N17321-6X	LDT	EN - DE
PERFINO V FREEZER 750 5000K CENTRE	8.5	950	110	N17329-6X	LDT	EN - DE
PERFINO V FREEZER 876 5000K CENTRE	10	1100	110	N17331-6X	LDT	EN - DE
PERFINO V FREEZER 1476 4000K CENTRE	18.5	1775	95	N17339-6X	LDT	EN - DE
PERFINO V FREEZER 1476 5000K CENTRE	18.5	2025	110	N17340-6X	LDT	EN - DE
PERFINO V FREEZER 1676 4000K CENTRE	21	2025	95	N17342-6X	LDT	EN - DE
PERFINO V FREEZER 1676 5000K CENTRE	21	2300	110	N17343-6X	LDT	EN - DE
PERFINO V FREEZER 1776 5000K CENTRE	22	2450	110	N17346-6X	LDT	EN - DE
PERFINO V FREEZER 750 5000K END	4.5	475	105	N17348-6X	LDT	EN - DE
PERFINO V FREEZER 876 5000K END	5.5	575	105	N17350-6X	LDT	EN - DE
PERFINO V FREEZER 1476 4000K END	9.5	850	90	N17358-6X	LDT	EN - DE
PERFINO V FREEZER 1476 5000K END	9.5	1000	105	N17359-6X	LDT	EN - DE
PERFINO V FREEZER 1676 4000K END	11	975	90	N17361-6X	LDT	EN - DE
PERFINO V FREEZER 1676 5000K END	11	1150	105	N17362-6X	LDT	EN - DE
PERFINO V FREEZER 1776 5000K END	11.5	1200	105	N17365-6X	LDT	EN - DE
PERFINO V CHILLER 876 3000K CENTRE	16	1525	95	N17367-6X	LDT	EN - DE
PERFINO V CHILLER 876 4000K CENTRE	16	1525	95	N17369-6X	LDT	EN - DE
PERFINO V CHILLER 876 3000K END	10	900	90	N17372-6X	LDT	EN - DE
PERFINO V CHILLER 876 4000K END	10	900	90	N17374-6X	LDT	EN - DE

Accessories

	Description	SKU	Datasheet
	PWM Dimmer 24V	N51570
	NPV-100-24 100W PSU, 24V, IP67, Metal, CB, VDE	N51057
